Bestal Vario Mesh

Limitless possibilities in a single sheet of mesh

Bestal’s Vario Mesh is one of the newest and most innovative forms of expanded metal. Developed through years of research & development and specialised machinery, this mesh range has special properties which offer breakthrough design possibilities, especially for building skins.

Bestal’s Vario Mesh allows you to incorporate and customise different designs and effects within the same sheet of mesh.

Vario Mesh offers varying levels of permeability and enlivens surfaces and structures. The result is that views into the building can be varied, allowing a high-degree of sun-shading and privacy at selected areas, as well as openness and permeability at other areas — all within the same sheet of mesh.


Applications

Facades

Facades

Fencing

Fencing


Materials

Steel

Steel

Stainless steel

Stainless steel

Galvanised steel

Galvanised steel

Aluminium

Aluminium

Mesh Ref. Material Mesh Opening (mm) Thickness (mm) Strand Width (mm)


SWM LWM

BVM2550Aluminium25502.0 - 4.03.0 - 10.0
BVM42115 Aluminium 42 115 2.0 - 4.0 15.0 - 25.0
BVM45135 Aluminium 45 135 2.0 - 4.0 15.0 - 25.0
BVM50152 Aluminium 50 152 2.0 - 4.0 17.0 - 30.0
BVM70150 Aluminium 70 150 2.0 - 4.0 20.0 - 30.0
BVM86200 Aluminium 86 200 2.0 - 4.0 25.0 - 35.0
BVM89200 Aluminium 89 200 2.0 - 4.0 25.0 - 35.0
BVM100200 Aluminium 100 200 2.0 - 4.0 30.0 - 40.0
BVM100250 Aluminium 100 250 2.0 - 4.0 30.0 - 40.0
BVM120250 Aluminium 120 250 2.0 - 4.0 30.0 - 40.0

*All thickness, strand and weight are subject to +/-10% tolerance *Standard sheets are 1220mm (LWM) x 2440mm (SWM)
