Bestal XG Mesh

The go-to safe and reliable option

Bestal XG Mesh is a quintessential expanded metal frequently used in public projects worldwide because of its high standard of safety and reliability.

As the industry-leading mesh for high quality and ability to withstand heavy-duty applications, it remains as the preferred choice for professionals.

Applications

Walkways, stair treads, factory platforms

Walkways, stair treads, factory platforms

Drain gratings

Drain gratings

Pedestrian barriers, safety guards, grilles

Pedestrian barriers, safety guards, grilles

Security installation

Security installation

Materials

Steel

Steel

Stainless steel

Stainless steel

Galvanised steel

Galvanised steel

Aluminium

Aluminium

Specifications

Mesh Ref. Material Mesh Opening (mm) Thickness (mm) Strand Width (mm) Weight
SWM LWM

(kg/m2)
XG-11Steel34135.44.57.014.50
XG-12Steel34135.46.07.019.40
XG-13Steel34135.46.09.024.90
XG-14Steel34135.48.09.033.20
XG-21Steel36101.64.57.013.70
XG-22Steel36101.66.07.018.30
XG-23Steel36101.66.09.023.60
XG-24Steel36101.68.09.031.40

*All thickness, strand and weight are subject to +/-10% tolerance *Standard sheets are 1220mm (LWM) x 2440mm (SWM)
